MERKUR System,pump Assy,x48

Type: Airless Sprayers

SKU 16U920

UPC 633955026520

Brand Graco

$6,585.60

Shipping calculated at checkout.

Stock adequate! Ready to ship

Payment & Security

Your payment is secure. We don’t store or see your card details.

View Full Details

Merkur 48:1 Cart-Mount Airless Sprayer Package, XTR-5 Gun, 519 XHD Tip, 25 ft (7.6 m) Hose, 6 ft (1.8 m) Whip Hose

MERKUR SYSTEM,PUMP ASSY,X48

Product Specifications

UPC Product: 633955026520
Division: CED
Family Code: FAMXTM
Country of Origin: US
Unit of Measure: EA
Height: 39.6 IN | 100.584 CM
Length: 24 IN | 60.960 CM
Width: 18 IN | 45.720 CM
Volume: 9.9 FT3 | 0.280 M3
Shipping Weight: 128.3 LBS | 58.196 KG
HTS Code (CA): 8424200000
HTS Code (US): 8424209000
Fluid Inlet Size (in): 1-1/4
Fluid Inlet Size (mm): 31.75
Fluid Outlet Size (mm): 9.525
Frame Configuration: Cart
Hose Inlet Diameter (cm): 0.9525
Hose Inlet Diameter (in): 3/8
Hose Inlet Diameter (mm): 9.525
Includes: XTR-7 Spray Gun, 519 XHD Tip, Fluid Hose
Maximum Sound Pressure Level (dB(A)): 68.9
Maximum Tip Size (in): 0.025
Maximum Working Pressure (psi): 4800
Maximum Working Pressure (kPa): 33100
Maximum Working Pressure (MPa): 33.1
Pressure Control Type: Air Regulator
Model: Merkur
Maximum Working Pressure (bar): 331
Weight (kg): 45
Series: X48/X72
Outlet Paint Filter: 60 Mesh Stainless Steel Screen
Pump Rod Type: Carbon Steel
Number of Guns: 1
Mount Type: Cart Mount
Pump Pressure Ratio: 48:1
Lower Configuration: Carbon Steel;1-1/4 in. Inlet;Drain Valve
Mix Ratio: 48:1
Maximum Air Consumption (SCFM): 60
Maximum Air Inlet Pressure (psi): 100
Maximum Operating Temperature (°C): 71
Maximum Operating Temperature (°F): 160
Fluid Outlet Thread Gender: Male
Volume Per Cycle (cm³): 75
