KING Sprayer,30:1,d-ice,hd,comp,aa

Type: Air-Assisted Airless Sprayers

SKU 287975

UPC 633955133747

Brand Graco

$9,853.20

Shipping calculated at checkout.

Stock adequate! Ready to ship

Payment & Security

Your payment is secure. We don’t store or see your card details.

View Full Details

Heavy-Duty Cart Mounted AA Spray Package with 30:1 Mix Ratio and De-Icing NXT Air Motor with DataTrak

KING SPRAYER,30:1,D-ICE,HD,COMP,AA

Product Specifications

UPC Product: 633955133747
Division: CED
Family Code: FAMXTM
Country of Origin: US
Unit of Measure: EA
Height: 60 IN | 152.400 CM
Length: 39.6 IN | 100.584 CM
Width: 31.2 IN | 79.248 CM
Volume: 42.9 FT3 | 1.215 M3
Shipping Weight: 308 LBS | 139.706 KG
HTS Code (CA): 8424200000
HTS Code (US): 8424209000
Maximum Working Pressure (psi): 3150
Model: King
Number of Guns: 1
Outlet Paint Filter: 60 Mesh
Overall Height (cm): 116.8
Overall Height (in): 46
Overall Height (mm): 1168.4
Pump Rod Type: Chromex
Weight (kg): 103
Convertible: Non-Convertible
Product Type: Single Leg
Pressure Control Type: Air Regulator
Overall Width (mm): 653.3
Overall Width (in): 25.72
Overall Width (cm): 65.3
Fluid Inlet Size (in): 1-1/4
Fluid Inlet Size (mm): 31.75
Material Application: Paints, Primers
Maximum Sound Pressure Level (dB(A)): 83
Fluid Outlet Size (mm): 12.7
Frame Configuration: Heavy-Duty Cart
Hose Inlet Diameter (cm): 0.9525
Hose Inlet Diameter (in): 3/8
Hose Inlet Diameter (mm): 9.525
Includes: De-Icing Motor, Heavy Duty Cart, G40 Spray Gun, Hose
Gun Model: G40
Maximum Working Pressure (bar): 217
Maximum Working Pressure (kPa): 21704

Documents

3A0149.pdf Download

3A5423.pdf Download

311164.pdf Download

3J0416EN.pdf Download
